BUTTERFLY VALVES M-F-1/2''-CIMBERIO
The Cimberio ½″ Union Ball Valve with Butterfly Handle (Fullway Type 346) combines:
Hygienic and smooth flow via its full-bore design.
Easy maintenance thanks to union joint construction.
Compact usability through its butterfly handle.
Dependable performance, rated for 25 bar and up to 120 °C.
Quality reassurance with leak testing, ISO compliance, and a generous 5-year warranty.
Available Offer
Product Details
Specifications Table – Cimberio Fullway T14 Type 346 (½″ M–F with Union)
Specification | Details |
|---|
Model / Series | Cimberio Fullway T14 (Type 346) |
Connection | ½″ Male–Female with Union joint |
Body Material | Brass (EN 12165 CW617N-DW) |
Ball Design | Full-bore, chrome-plated, mirror finish |
Handle Type | Butterfly (aluminium alloy) |
Nominal Pressure (PN) | 25 bar |
Operating Temperature | –20 °C to +120 °C |
Flow Coefficient (Kv) | 17 m³/h @ 1 bar Δp |
Operating Torque (Cm) | 3 Nm |
Starting Torque (Cs) | 6 Nm |
Stem Break Torque (MT) | 10 Nm |
Standards & Testing | ISO 9001; leak-tested per EN 12266-1 |
Warranty | 5 years |
Typical Applications | Heating, HVAC, sanitary, pneumatic, non-corrosive fluids |
