BUTTERFLY VALVES M-F-3/4''-CIMBERIO

Model / Series

Cimberio Fullway T14 – Type 346

Connection

¾″ Male–Female union joint

Material

Brass (EN 12165 CW617N-DW)

Ball Design

Full-bore, chrome-plated, mirror finish

Handle Type

Butterfly (aluminum alloy) handle

Nominal Pressure (PN)

PN 25 (25 bar)

Operating Temperature

–20 °C to +120 °C

Flow Coefficient (Kv)

41 m³/h @ 1 bar Δp (¾″ size)

Operating Torque (Cm)

5 Nm

Starting Torque (Cs)

10 Nm

Stem Break Torque (MT)

24 Nm

Standards & Testing

ISO 9001; EN 12266-1 leak-tested

Warranty

5 years

Weights & Dimensions (¾″)

Weight: 435 g; A=70 mm; B=56 mm; C=86.5 mm; D=12.5 mm; CH=31 mm
