ENGO ECB8-230
The ENGO ECB8-230 is a professional 230V wired control strip engineered for multi-zone underfloor heating systems. It supports up to 8 independent heating zones, integrates boiler and pump control modules with safe low-voltage operation, and provides versatile, volt-free outputs for reliable system management. Designed for use with 230 V actuators and wired thermostats, the ECB8-230 is ideal for residential and commercial underfloor heating applications where centralized control and robust performance are required
SKU - ENGWCECB8230
€89,83
€89,84
Share:
Product Details
| Parameter | Specification |
|---|---|
| Product Type | Underfloor Heating Control Strip |
| Model | ECB8-230 |
| Power Supply | 230 V, 50 Hz |
| Zones | Up to 8 independent heating zones |
| Load Capacity (Total Strip) | 10 A max |
| Pump Control Output | Volt-free COM/NO, max 6 A |
| Boiler Control Output | Volt-free NO/COM/NC, max 6 A |
| Actuator Outputs | 23 230V for thermoelectric actuators |
| Compatible Controllers | Wired 230 V thermostats or battery thermostats |
| Mounting | Flat surface or DIN rail |
| Built-In Features | Pump & boiler switch-on delay for equipment protection |
| Connectors | Removable terminal blocks for easy wiring |
| Dimensions (mm) | ~330 × 110 × 36 mm |
| Application Areas | Underfloor heating systems in residential & commercial buildings |
| Compliance | CE / EU directives (EMC, LVD, RoHS) |
