Victaulic
VICTAULIC BUTTERFLY VALVE WITH ACTUATOR 705-2.5''
Victaulic FireLock® Series 705 2.5" grooved butterfly valve with weatherproof actuator — designed for fire protection and HVAC piping systems. Ductile iron body and EPDM sealing provide reliable shut-off and supervised operation in grooved-end installations.
€279,32
€279,33
Choose Qty:
Product Details
| Specification | Details |
|---|---|
| Manufacturer | Victaulic |
| Series / Model | FireLock® Series 705 |
| Size | 2.5″ (DN65 approx.) |
| Connection Type | Grooved End (Victaulic Original Groove System) |
| Actuator | Weatherproof housing (handwheel / supervised actuator) |
| Body Material | Ductile Iron (ASTM A536) |
| Disc Material | Ductile Iron with suitable coating |
| Seat / Seal | EPDM |
| Stem Material | Stainless Steel |
| Pressure Rating | Up to 300 psi / 2068 kPa / 21 bar service |
| Standards & Approvals | cULus Listed, FM, LPCB, VdS (varies by region & model) |
| Finish | Black alkyd enamel |
| Applications | Fire protection systems, HVAC systems |
| Available Sizes | 2″ – 12″ (including 2.5″) Grooved valves in Series 705 |
